Description
Our LED Wall Pack fixtures are great replacements for outdoor, forward throw Metal Halide or Sodium Potassium bulbs. They will replace anywhere from 150W HPS/MH and provide sufficient lumens in majority of applications. Additionally, our Wall Packs are easy to install and provide convenient operating features such as our "Instant Start." Moreover, these LED Wall Packs provide superior lighting without Flickering or Humming. Also, the output constant current lever can be adjusted through output cable with 1-10V. Our LED Wall Pack is Eco-Friendly which means there is NO Mercury. With this improved lighting, there is no UV or IR in the beam. Furthermore, these fixtures come with a 5 year warranty.
This product is listed under DesignLights Consortium® (DLC) which does not only provide eligibility for rebates from most utility providers, but also promotes high-quality and energy-efficient lighting products through vigorous testing protocols.
Specifications
SKU: 107-100093
Qualification: UL, cUL, DLC 5.1
Dimensions (LxHxW): 14.17in x 9.25in x 9.65in
Shipping Dimensions (LxHxW): 15.75in x 11.81in x 12.01in
Watts: 150W
Dimming: 0-10V
Weight: 11.24 lbs
Shipping Weight: 13.23 lbs
Lumens: 19950 Lumens
Lumens Efficacy: 133 lm/w
Color: 5000K
Input Voltage: 120-277Vac 50/60Hz
IP Rating: IP65 Rated
Housing: Aluminum(ADC12) +PC
Viewing Angle (°): 100°
CRI: >80
PF: >0.9
LED Type: Lumileds 2835
Lifespan: 50,000 hours
Replaces: up to 500W HID
Warranty: 5 years
Product Spec Sheet
Click Here to view the Product Spec Sheet.
Notice For User:
- Please turn off power before install or change assembly parts.
- The input voltage and lamps should be matched, after connecting the power line, please make sure the wiring section is insulated.
- Professionals only, must install and disassemble the lamps.
